GMQ 1800M

GMQ 1800M

Cutter pump technology designed to prevent fibrous waste from obstructing the flow.

• Integrated cutter system
• Heavy-duty non-clog design
• IP68 protection for fully submersible operation
• Stainless steel motor casing
• Cast iron casing and impeller
• Motor with thermal protection
• Integrated float switch
• Solids handling capacity up to 38 mm
• Designed for continuous operation
• Suitable for domestic and industrial wastewater applications

• Maximum Flow Rate (Q): 23 m³/h
• Maximum Head (H): 26 mWC
• Motor Power: 1.8 kW
• Voltage: Single-phase 230 V
• Protection Class: IP68
• Frequency: 50 Hz
• Compliant with EN and IEC standards
• Maximum Submersion Depth: 5 m
• Maximum Solids Size: 38 mm
• Fluid Temperature: Up to 40 °C
• Discharge Connection: G2"

• Cast iron casing
• Cast iron impeller
• Cutter blade system
• AISI 304 stainless steel motor casing
• AISI 304 stainless steel shaft
• Silicon carbide/graphite mechanical seal
• Thermal protection system

• Domestic wastewater systems
• Industrial wastewater applications
• Sewage lifting systems
• Wastewater treatment plants
• Drainage applications
• Rainwater harvesting systems
